### Roll your own Style
You can also roll your own style:
```golang
t.SetStyle(table.Style{
Name: "myNewStyle",
Box: table.BoxStyle{
BottomLeft: "\\",
BottomRight: "/",
BottomSeparator: "v",
Left: "[",
LeftSeparator: "{",
MiddleHorizontal: "-",
MiddleSeparator: "+",
MiddleVertical: "|",
PaddingLeft: "<",
PaddingRight: ">",
Right: "]",
RightSeparator: "}",
TopLeft: "(",
TopRight: ")",
TopSeparator: "^",
UnfinishedRow: " ~~~",
},
Color: table.ColorOptions{
IndexColumn: text.Colors{text.BgCyan, text.FgBlack},
Footer: text.Colors{text.BgCyan, text.FgBlack},
Header: text.Colors{text.BgHiCyan, text.FgBlack},
Row: text.Colors{text.BgHiWhite, text.FgBlack},
RowAlternate: text.Colors{text.BgWhite, text.FgBlack},
},
Format: table.FormatOptions{
Footer: text.FormatUpper,
Header: text.FormatUpper,
Row: text.FormatDefault,
},
Options: table.Options{
DrawBorder: true,
SeparateColumns: true,
SeparateFooter: true,
SeparateHeader: true,
SeparateRows: false,
},
})
```
Or you can use one of the ready-to-use Styles, and just make a few tweaks:
```golang
t.SetStyle(table.StyleLight)
t.Style().Color.Header = text.Colors{text.BgHiCyan, text.FgBlack}
t.Style().Color.IndexColumn = text.Colors{text.BgHiCyan, text.FgBlack}
t.Style().Format.Footer = text.FormatLower
t.Style().Options.DrawBorder = false
```
## Auto-Merge
You can auto-merge cells horizontally and vertically, but you have request for
it specifically for each row/column using `RowConfig` or `ColumnConfig`.
```golang
rowConfigAutoMerge := table.RowConfig{AutoMerge: true}
t := table.NewWriter()
t.AppendHeader(table.Row{"Node IP", "Pods", "Namespace", "Container", "RCE", "RCE"}, rowConfigAutoMerge)
t.AppendHeader(table.Row{"", "", "", "", "EXE", "RUN"})
t.AppendRow(table.Row{"1.1.1.1", "Pod 1A", "NS 1A", "C 1", "Y", "Y"}, rowConfigAutoMerge)
t.AppendRow(table.Row{"1.1.1.1", "Pod 1A", "NS 1A", "C 2", "Y", "N"}, rowConfigAutoMerge)
t.AppendRow(table.Row{"1.1.1.1", "Pod 1A", "NS 1B", "C 3", "N", "N"}, rowConfigAutoMerge)
t.AppendRow(table.Row{"1.1.1.1", "Pod 1B", "NS 2", "C 4", "N", "N"}, rowConfigAutoMerge)
t.AppendRow(table.Row{"1.1.1.1", "Pod 1B", "NS 2", "C 5", "Y", "N"}, rowConfigAutoMerge)
t.AppendRow(table.Row{"2.2.2.2", "Pod 2", "NS 3", "C 6", "Y", "Y"}, rowConfigAutoMerge)
t.AppendRow(table.Row{"2.2.2.2", "Pod 2", "NS 3", "C 7", "Y", "Y"}, rowConfigAutoMerge)
t.AppendFooter(table.Row{"", "", "", 7, 5, 3})
t.SetAutoIndex(true)
t.SetColumnConfigs([]table.ColumnConfig{
{Number: 1, AutoMerge: true},
{Number: 2, AutoMerge: true},
{Number: 3, AutoMerge: true},
{Number: 4, AutoMerge: true},
{Number: 5, Align: text.AlignCenter, AlignFooter: text.AlignCenter, AlignHeader: text.AlignCenter},
{Number: 6, Align: text.AlignCenter, AlignFooter: text.AlignCenter, AlignHeader: text.AlignCenter},
})
t.SetOutputMirror(os.Stdout)
t.SetStyle(table.StyleLight)
t.Style().Options.SeparateRows = true
fmt.Println(t.Render())
```
to get:
```
┌───┬─────────┬────────┬───────────┬───────────┬───────────┐
│ │ NODE IP │ PODS │ NAMESPACE │ CONTAINER │ RCE │
│ │ │ │ │ ├─────┬─────┤
│ │ │ │ │ │ EXE │ RUN │
├───┼─────────┼────────┼───────────┼───────────┼─────┴─────┤
│ 1 │ 1.1.1.1 │ Pod 1A │ NS 1A │ C 1 │ Y │
├───┤ │ │ ├───────────┼─────┬─────┤
│ 2 │ │ │ │ C 2 │ Y │ N │
├───┤ │ ├───────────┼───────────┼─────┴─────┤
│ 3 │ │ │ NS 1B │ C 3 │ N │
├───┤ ├────────┼───────────┼───────────┼───────────┤
│ 4 │ │ Pod 1B │ NS 2 │ C 4 │ N │
├───┤ │ │ ├───────────┼─────┬─────┤
│ 5 │ │ │ │ C 5 │ Y │ N │
├───┼─────────┼────────┼───────────┼───────────┼─────┴─────┤
│ 6 │ 2.2.2.2 │ Pod 2 │ NS 3 │ C 6 │ Y │
├───┤ │ │ ├───────────┼───────────┤
│ 7 │ │ │ │ C 7 │ Y │
├───┼─────────┼────────┼───────────┼───────────┼─────┬─────┤
│ │ │ │ │ 7 │ 5 │ 3 │
└───┴─────────┴────────┴───────────┴───────────┴─────┴─────┘
```
## Paging
You can limit then number of lines rendered in a single "Page". This logic
can handle rows with multiple lines too. Here is a simple example:
```golang
t.SetPageSize(1)
t.Render()
```
to get:
```
+-----+------------+-----------+--------+-----------------------------+
| # | FIRST NAME | LAST NAME | SALARY | |
+-----+------------+-----------+--------+-----------------------------+
| 1 | Arya | Stark | 3000 | |
+-----+------------+-----------+--------+-----------------------------+
| | | TOTAL | 10000 | |
+-----+------------+-----------+--------+-----------------------------+
+-----+------------+-----------+--------+-----------------------------+
| # | FIRST NAME | LAST NAME | SALARY | |
+-----+------------+-----------+--------+-----------------------------+
| 20 | Jon | Snow | 2000 | You know nothing, Jon Snow! |
+-----+------------+-----------+--------+-----------------------------+
| | | TOTAL | 10000 | |
+-----+------------+-----------+--------+-----------------------------+
+-----+------------+-----------+--------+-----------------------------+
| # | FIRST NAME | LAST NAME | SALARY | |
+-----+------------+-----------+--------+-----------------------------+
| 300 | Tyrion | Lannister | 5000 | |
+-----+------------+-----------+--------+-----------------------------+
| | | TOTAL | 10000 | |
+-----+------------+-----------+--------+-----------------------------+
```
## Sorting
Sorting can be done on one or more columns. The following code will make the
rows be sorted first by "First Name" and then by "Last Name" (in case of similar
"First Name" entries).
```golang
t.SortBy([]table.SortBy{
{Name: "First Name", Mode: table.Asc},
{Name: "Last Name", Mode: table.Asc},
})
```
## Wrapping (or) Row/Column Width restrictions
You can restrict the maximum (text) width for a Row:
```golang
t.SetAllowedRowLength(50)
t.Render()
```
to get:
```
+-----+------------+-----------+--------+------- ~
| # | FIRST NAME | LAST NAME | SALARY | ~
+-----+------------+-----------+--------+------- ~
| 1 | Arya | Stark | 3000 | ~
| 20 | Jon | Snow | 2000 | You kn ~
+-----+------------+-----------+--------+------- ~
| 300 | Tyrion | Lannister | 5000 | ~
+-----+------------+-----------+--------+------- ~
| | | TOTAL | 10000 | ~
+-----+------------+-----------+--------+------- ~
```
## Column Control - Alignment, Colors, Width and more
You can control a lot of things about individual cells/columns which overrides
global properties/styles using the `SetColumnConfig()` interface:
- Alignment (horizontal & vertical)
- Colorization
- Transform individual cells based on the content
- Visibility
- Width (minimum & maximum)
```golang
nameTransformer := text.Transformer(func(val interface{}) string {
return text.Bold.Sprint(val)
})
t.SetColumnConfigs([]ColumnConfig{
{
Name: "First Name",
Align: text.AlignLeft,
AlignFooter: text.AlignLeft,
AlignHeader: text.AlignLeft,
Colors: text.Colors{text.BgBlack, text.FgRed},
ColorsHeader: text.Colors{text.BgRed, text.FgBlack, text.Bold},
ColorsFooter: text.Colors{text.BgRed, text.FgBlack},
Hidden: false,
Transformer: nameTransformer,
TransformerFooter: nameTransformer,
TransformerHeader: nameTransformer,
VAlign: text.VAlignMiddle,
VAlignFooter: text.VAlignTop,
VAlignHeader: text.VAlignBottom,
WidthMin: 6,
WidthMax: 64,
}
})
```
## Render As ...
Tables can be rendered in other common formats such as:
### ... CSV
```golang
t.RenderCSV()
```
to get:
```
,First Name,Last Name,Salary,
1,Arya,Stark,3000,
20,Jon,Snow,2000,"You know nothing\, Jon Snow!"
300,Tyrion,Lannister,5000,
,,Total,10000,
```
### ... HTML Table
```golang
t.Style().HTML = table.HTMLOptions{
CSSClass: "game-of-thrones",
EmptyColumn: " ",
EscapeText: true,
Newline: "| # | First Name | Last Name | Salary | |
|---|---|---|---|---|
| 1 | Arya | Stark | 3000 | |
| 20 | Jon | Snow | 2000 | You know nothing, Jon Snow! |
| 300 | Tyrion | Lannister | 5000 | |
| Total | 10000 |
